  • sketch Swivel bracket 100 mm 2

Swivel bracket 100 mm

Article number:
581000-5
PDF Sheet

Swivel bracket. Made of zinc-chromatized pressed sheet metal with double ball race swivel. Center hole fitting for M12 screw.

For price information, please log in.

Specifications

Diameter 100 mm
Totalt height 132 mm
Fitting Center hole
Rolling resistance 1 = Heavy to roll, 5 = Easy to roll
Sound level 1 = Loud, 5 = Quiet
Wear 1 = Quick wear, 5 = Slow wear
Rust protection 1 = Low rust protection, 5 = Stainless
Diameter 100 mm
Totalt height 132 mm
Fitting Center hole
Centre Bolt Hole 12.4 mm
Hub Hole Diameter 10 mm
Fork Width 47 mm
Offset 41 mm
Material Thickness Bracket 2.5 mm
Temperature Range -20°C to +70°C
Numeric values in the technical specification may be nominal/rounded to the nearest standard dimension. To see exact values, please refer to the drawing.
